Mark-10 M3-100 Series M3 Digital Force Gauge, 100lbF Capacity

Mark-10 M3-100 Force Gauge, 100 lbF / 50 kgF / 500 NSeries 3 digital force gauges are designed for tension and compression force testing in numerous applications from 0.12 lbF to 500 lbF (0.5 N to 2500 N). The gauges feature a sampling rate of 2,000 Hz, producing accurate results under a wide range of test conditions. A backlit graphic LCD displays large characters, and a menu is available to access the gauges' features and configurable parameters. USB output is provided for data collection purposes.Set point indicators are provided for pass-fail testing. The gauges are overload protected to 150% of capacity, and an analog load bar is shown on the display for graphical representation of applied force.An ergonomic, reversible aluminum housing allows for handheld use or test stand mounting for more sophisticated testing requirements. Series 3 digital force gauges are directly compatible with Mark-10 test stands, grips, and software.Series 3 gauges include MESUR Lite data acquisition software, for tabulation of continuous or individual data points. One-click export to Excel button easily allows for further data manipulation.Display IndicatorsFocus on Engineering: Reversible HousingDimensions in [mm]Optional Equipment A wide range of test stands and gripping fixtures MESUR gauge Software - tabulates and plots load vs. time or load vs. travel. Also calculates statistics, exports to Excel, generates reports, and more. Certificate of calibration with data Mounting plate For mounting Mark-10 gauges to a fixture or testing system. Includes mounting hardware. Note: Gauge mounting plates are included with Mark-10 test stands. Eye End Adapters Allow for quick grip installation and removal, and prevent grip rotation. Mount to common test frames, load cells, and force gauges.
