PLC HMI All in One Integrated Programmable Logic Controller H3G-18MR, 4 Inch TFT Display, Built-in 2AD 2DA and 2NTC10K Temperature, 4 Channel High Speed, 1 Modbus RS485 (F420-H3G-B-RS485)
This item may be available in a different size, colour, scent, version or platform:
PLC HMI All in One Integrated Programmable Logic Controller H3G-18MR, 4 Inch TFT Display, Built-in 2AD 2DA and 2NTC10K Temperature, 4 Channel High Speed, 1 Modbus RS485 (F420-H3G-B-RS485)
--- PLC Type: Compatible with H3G, 10 Input (NPN Type) 8 Relay Output. 2 channel X0 X1 high speed input 100KHz to control Encoder. Have additional 8 Transistors Output: 4 channels high speed puls 100kHz to drive 4 servos or 4 steppers. Pulse single is 5V not 24V
--- Built-In 2 Analog input (0-10V) and 2 analog output (0-10V), 2 channels for temparature NTC10K B3435 probe, can read the teamparature from register address directly, 1 Channel for Modbus RS485. Pls disconnect the download cable when read the AD DA and NTC10K value, or cannot read it.
- PLC Software: Use GX Workers 2 or Developer (pls download from GX Workers 2 website, we only have Chinese version), support Command + T Ladder Diagram + SFC for programming
-- HMI Softare English version: YKBuilder V5.3 / 7.0 Very easy to use this configuration software (Pls contact us, we will share it and the video instruction and guidelines)
-- Project dowload: Use the same Cable for download program from PC to PLC/HMI: Use the mini port – USB cable, pls install HMI & PLC’s USB driver which we will share with you
